Details
| Weight
|
Shipping Weight |
9630 kg |
| Operating Weight |
9705 kg |
| Motor
|
Type |
4TNV98CT-VBV2 |
| Fuel |
Diesel |
| Net Power |
51.0 kW/69.3 HP at 2 100 min |
| Rated power |
53.7 kW/72.3 HP at 2 100 min |
| Displacement |
3,318 l |
| Maximum torque |
283-308 Nm |
| Starter |
12V - 3kW |
| Battery |
12V - 100Ah (for 20 hours) |
| Alternator |
12V - 80A |
| Hydraulic system
|
Maximum pressure |
275 bars |
| Service pump |
Piston pump with variable flow rate |
| Maximum flow |
137.8 l/min |
| Hydraulic Tank |
at |
| Performance
|
Walking speed |
2.1/4.3 km/h |
| Rotation speed |
9.0 min |
| Digging force (arm) |
45.9/42.2 kN |
| Digging force (bucket) |
68.4 kN |
| Tractive force |
75.5 kN |
| Noise level (2000/14/EC & 2005/88/EC) |
LpA:97.5 dBA; LpA:76 dBA |
| Fuel tank |
115 l |
