Details
| Weight
|
shipping weight |
1170 kg |
| Operating Weight |
1245 kg |
| Motor
|
Type |
3TNV70-WBVB |
| Fuel |
Diesel |
| Net Power |
9.2 kW / 12.5 hp / 2000 rpm |
| Rated power |
9.3 kW / 12.6 hp / 2000 rpm |
| displacement |
0.854 l |
| Maximum torque |
48.1 ~ 52 Nm at 1500 rpm |
| Starter |
12V - 1.1 kW |
| Battery |
12V – 36Ah |
| Alternator |
14V – 8.5A |
| Hydraulic system |
Maximum pressure |
210 bar |
| service pump |
Double piston pump with variable flow |
| Maximum flow |
2 x 11 l/min |
| Hydraulic Tank |
7.4 l |
| performance
|
speed of progress |
2.1 - 4 km/h |
| Rotation speed |
10 rpm |
| Digging force (arm) |
5.68 kN |
| Digging Force (bucket) |
13.63 kN |
| Tractive force |
at |
| Noise level (2000/14/EC & 2005/88/EC) |
88 dBA |
| Fuel tank |
12 l |
