Weight Shipping Dimensions 5320 x 2220 x 2765 mm Operating Weight 5800 kg Motor Type 4TNV98CT Fuel Diesel Net Power 53.7 kW (73 hp) displacement 3,318 cm3 Maximum torque 308 Nm at 1365 rpm Starter 12V - 3 kW Battery 12V – 100Ah Alternator 14V - 80A Hydraulic system service pump Hydraulic proportional valve three-way control lever (joystick) Maximum flow 76 l/min operating pressure 250 bar Hydraulic Tank 88 l tempo system front axle Rigid planetary final driveshaft, center mounted disc brake.

Slip differential limit 35%

rear axle Oscillating planetary final driveshaft, with integrated reduction gear, locking

oscillation with rotating top carriage. Limited slip differential 35%

Tires (standard) 405 /70R 20 SPT9 Dunlop speed of progress 0 - 20 km/h sound level sound level LwA = 101 dB(A) / LpA = 74 dB(A)
