Weight Transport Dimensions 5238 x 1850 x 2499 mm Operating Weight 4250 kg Motor Type 4TNV86CT Fuel Diesel Net Power 35.5 kW (64 hp) Displacement 2,091 cm³ Maximum torque 177 Nm at 1,560 rpm Starter 2.3 Kw Battery 12 V / 77 Ah Alternator 14V/80A Hydraulic system Service pump Four-way proportional hydraulic valve control lever (joystick) for operating the lift and tilt cylinders with integrated travel direction and speed range button. Maximum flow 63 l/min Operating pressure 250 bar Hydraulic Tank - Tempo system Front axle Rigid planetary final drive shaft, center mounted disc brake.

Slip differential limit 35%

Rear axle Oscillating planetary final drive shaft, with integrated reduction gear, locking

oscillation with rotating upper carriage. Limited slip differential 35%

Tires (standard) 340 /80 - 18” Walking speed 0 - 20 km/h Sound level Sound level LwA = 101 dB(A) / LpA = 78 dB(A)
