Weight Shipping Dimensions 5060 x 1850 x 2640 mm Operating Weight 4900 kg Motor Type 4TNV98C Fuel Diesel Net Power 46.2 kW (63 hp) at 2200 rpm displacement 3,318 cm3 Maximum torque 241 Nm at 1,430 rpm Starter 12V - 3 kW Battery 12V – 100Ah Alternator 14V - 80A Hydraulic system service pump Hydraulic proportional valve four-way control lever (joystick) Maximum flow 65 l/min operating pressure 250 bar Hydraulic Tank 55 l tempo system front axle Rigid planetary final driveshaft, center mounted disc brake.

Slip differential limit 35%

rear axle Oscillating planetary final driveshaft, with integrated reduction gear, locking

oscillation with rotating top carriage. Limited slip differential 35%

Tires (standard) 405/70 R 18 SPT9 Dunlop speed of progress 0 - 20 km/h sound level sound level LwA = 101 dB(A) / LpA = 78 dB(A)
